Product Center

JT2023 Thermal Anemometer

Model: JT2023

JT2023 Wind speed meter adopts thermal wind speed probe, its working principle is wind cooling principle, can choose omnidirectional (non-directional) (JT2023A type) or directional wind speed probe (JT2023B type), omnidirectional wind speed probe does not need to rotate during measurement The correct reading can be obtained only in the direction of the probe, and the directional wind speed probe needs to rotate the probe during measurement to find the maximum reading in order to read the correct measurement value.

How to Contact Us

Tel:+86 10 64219138
Email:info@bjjttec.com

Price

Product inquiry
Product Introduction
  • JT2023 wind speed meter adopts thermal wind speed probe, its working principle is wind cooling principle, can choose omnidirectional (non-directional) (JT2023A type) or directional wind speed probe (JT2023B type), omnidirectional wind speed probe does not need to rotate during measurement The correct reading can be obtained only in the direction of the probe, and the directional wind speed probe needs to rotate the probe during measurement to find the maximum reading in order to read the correct measurement value. JT2023 Micro-Anemometer is a precision product, which is widely used in occupational health, construction, industry, agriculture and other fields. It is mainly used in low wind speed and high precision occasions, such as measuring indoor airflow field in buildings, wind speed monitoring in tobacco production workshops, tea workshops, etc. , the probe can output wind speed and wind temperature at the same time.
Features
  • High-precision low wind speed measurement, optional omnidirectional or directional wind speed probe (extensible) to
    measure wind speed and wind temperature at the same time
    Real-time measurement curve display
    Built-in high-capacity memory card, which can record massive measurement data
    Built-in large-capacity lithium battery, standby time up to 48 The hour (JT2023B type)
    unit is automatically converted, and m/s, m/min, km/h are displayed at the same time
Product Performance
  • JT2023A
    Configure an omnidirectional wind speed probe

    The omnidirectional wind speed probe has a very high response speed, the fastest can reach 200ms, it can detect weakly changing airflow, and has perfect consistency in the horizontal direction, it is widely used in measuring the wind speed of biological safety cabinets, clean room wind speed, precision machining workshop etc.

    JT2023B
    Configuring Directional Wind Speed ??Probes

    The omnidirectional wind speed probe has a very high response speed, the fastest can reach 200mns, it can detect weakly changing airflow, and has perfect consistency in the horizontal direction, it is widely used in measuring the wind speed of biological safety cabinets, clean room wind speed, precision machining workshop etc.
Technical Parameters
Parameter name
Technical Indicators
illustrate
Model Specifications
JT2023A Wind Speed ??Tester
JT2023B Wind Speed ??Tester
?
Wind speed measurement range
0-5m/s
0-20m/s
?
precision
0.05-2.0m/s ±(0.05 m/s+2% of reading)? ??2.0-5.0m/s ±(0.1 m/s±2% of reading)
±(0.1m/s±2% of reading)
?
resolution
0.01m/s
0.01m/s
?
sensor type
hot bulb
hot bulb
?
Units of measurement
m/s, m/min, km/h displayed at the same time
m/s, m/min, km/h displayed at the same time
?
Temperature measurement range
-20-70°C
-20-70°C
?
temperature accuracy
±0.5°C
±0.5°C
?
temperature resolution
0.1°C
0.1°C
?
storage interval
Adjustable from 1 second to 60 minutes
?
display screen
3.5-inch LCD display, which can display measured values ??and curves
?
measurement standard
wind speed, temperature
?
data storage
Pluggable SD memory card
?
Battery
36 hours standby time after fully charged
48 hours standby time after fully charged
?
data transfer interface
micro USB
?
software
JTSOFT-MT
?
language options
Chinese/English
?
Appearance size (mm)
175X92X38mm
?
Weight (g) About 350g (host)
?
use environment
-10-60℃,0-95%RH
the host
storage environment
-20℃-60℃,0-95%RH
?
Standard configuration
Host, wind speed probe, software (U disk), USB data cable, instrument case
?
